SC91 Italian worm

发布时间:2023-01-04人气:123

When SC91 was originally designed, the idea was particularly simple, to make a desktop single-flavor ice cream machine with a worm gear.


The design plan is perfect, but the reality is very skinny. It took a year and a half of detours in the choice of worm gear suppliers (mainly the stability of the quality of worm gear products).

But at the same time, it was also very lucky. In 2017, the ice cream machine manufacturer established a cooperation with an Italian brand specializing in worm gear and worm gear box motors. It took 4 months from the sample to the commissioning to determine the various standards.


During these 4 months, the supplier's technical team came to the factory to play a key role.


Therefore, the SC91 that everyone sees today has been very popular in Dubai/Australia/New Zealand/Singapore/Malaysia/Indonesia and has been sold steadily for 2 years.

Large capacity hopper: 15L hopper


Super quiet: Italian worm gear box + motor drive system


Throat seat lock function: a safety system to protect operators


Pre-cooling and fresh-keeping system: a new upgraded version of pre-cooling and fresh-keeping in Germany in 2018

Remarks: The reference output data in the parameter list all come from the temperature/humidity/raw material/machine placement environment of the company's test room.



 MODEL

 SC91

 VOLTAGE

 220V/50HZ

 MAIN POWER

 2000W

 Electric current

 1* 9A(ampere)

 MAIN COMPRESSOR

 France Tecumseh

 PER-COOLING GAS

 R134A

 PER-COOLING SYSTEM

 2~10℃ adjustable

 Per-cooling capacity

 1* 490BTU

 PRODUCING GAS

 R404A

 Producing capacity

 1* 5865BTU

 Hardness setting

 1~15 gear adjustable

 First overload time

 7~16min (material 5~15 ℃)

 Reference output

 6~8CUP (80g/CUP)/TIME

Interval overload time

 2~4 min(material 5~10 )

 Puffing system 1

 1~4 gear expansion tube Adjustable

 Puffing system 2

 Gravity expansion pump (optional)

 Expansion pump drive

 Italian worm gear box motor

 HOPER

 1 x 15L

 CYLIMDER

 1 x 2.1L

 NET WEIGHT

 126 KG

 PRODUCT SIZE

 700 x 520 x 790(mm)

 PACKING SIZE

 900 x 680 x 1000(mm)
